Compare Truck & SUV Winches



Standard Duty

Premium

Ultimate Performance

Heavyweight

Features

Available Capacities (lbs.)

8,000, 10,000, and 12,000
8,000, 10,000, and 12,000
10,000 and 12,000
12,000, 15,000, and 16,500

Suitable Vehicles

SUVs and trucks with GVWR* of up-to 8,000lbs. Recommendedwinch capacity =1.5 x GVWR
SUVs and trucks with GVWR* of up-to 8,000lbs. Recommendedwinch capacity =1.5 x GVWR
SUVs and trucks with GVWR* of up-to 8,000 lbs.Recommended winch capacity = 1.5 x GVWR
Large SUVs & trucks with GVWR* of up-to 11,000lbs. Recommended winch capacity = 1.5 x GVWR

Anchoring System

Drum flange screw and thimble
Patented through-drum technology
Patented through-drum technology
Drum flange screw and thimble

Motor & Gear Train armor

None
Full metal armor
Full metal armor
None

Control Pack Material

Impact-resistant composite
Full metal armor
Full metal armor
Plastic on M12 and M15.Metal on 16.5Ti

Wiring

Traditional Motor terminals
Automotive OE—grade bus bar
Automotive OE—grade bus bar
Traditional Motor terminals

Remote Control

Traditional design remotetoggle switch
IP68 Waterproofergonomic remote with large rocker switch
IP68 Waterproof Advancedwireless Control
IP68 Waterproof ergonomic remote with large rocker switch

Performance Sensors

None
None
Actively monitors winchtemperature and vehiclebattery condition
None

Clutching Mechanism

Manual lever operation
Manual lever operation
Automatic operation via wireless remote
Manual lever operation

Clutch Lever

Black easy-grip handle
Stainless steel easy-grip handle
None (Remote-operated clutch)
Polished silver bent bar handle

Auxiliary Plug-In

None
None
2 auxiliary accessories, control via wireless remote
None

Synthetic Rope

Standard Duty synthetic rope
Spydura and SpyduraPro synthetic rope
Spydura and Spydura Prosynthetic rope
Spydura and Spydura Prosynthetic rope

Hawse Fairlead

Cast ductile iron
Cast aluminum
Cast aluminum
Cast aluminum

Brake System

3-segment mechanical cone brake
6-segment mechanical cone brake
3-segment mechanical cone brake with a steel sleeve 3-segment mechanical cone brake
Platinum’s unique design allows for increased linespeed over the ZEON

Winch Structural Bracing

Tie plate
Tie plate
Tie plate
Tie rods

Final Point of Assembly

Warn-exclusive partnerin China
Warn facility in Oregon, USA
Warn facility in Oregon, USA
Warn facility in Oregon,USA

Winch Drum

2.5"-2.625” diameterwelded steel drum
3.15” diameteraluminum orzinc-alloy drum
3.15” diameterzinc-alloy drum
3.5” diameterwelded steel drum

Weight

54–76 lbs.
75–98 lbs.
83–98 lbs.
89–138 lbs.

Dimensions(L x D x H)

Integrated Configuration:VR8 and VR10:20.8” x 6.3” x 9.8”VR12: 21.9” x 6.3” x 9.8”
Integrated Configuration:24.3” x 7.2” x 10.6”
Integrated Configuration:24.3” x 7.2” x 10.6”
With Control Pack:M-12 and M-15:25.2” x 8.5” x 11”16.5Ti: 24.2” x 8.5” x 9.7”

Low Profile Height

7.1” (without control pack)
7.9” (without control pack)
7.9” (without control pack)
8.6” (without control pack)

Mounting Pattern

10” x 4.5”
10”x 4.5”
10” x 4.5”
10” x 4.5”

Performance

No Load Line Speed

28.4 (VR12, 12-S)26 ft/min (VR10, 10-S)29 ft/min (VR8, 8-S)
28.1 ft/min (ZEON 12, 12-S)33 ft/min (ZEON 10, 10-S)35 ft/min (ZEON 8, 8-S)
33 ft/min (12, 12-S Platinum)44 ft/min (10, 10-S Platinum)
23.6 ft/min (16.5ti, ti-S)22.2 ft/min (M15, M15-S)30 ft/min (M12, M12-S)ZEON Platinum has a 70% faster no-load linespeed than VR, 33% vs. ZEON for rapid recovery

Full Load Line Speed

3.6 ft/min (VR12, 12-S)2.3 ft/min (VR10, 10-S)4.8 ft/min (VR8, 8-S)
3.1 ft/min (ZEON 12, 12-S)4.8 ft/min (ZEON 10, 10-S)6.2 ft/min (ZEON 8, 8-S)
4.5 ft/min (12, 12-S Platinum)5.5 ft/min (10, 10-S Platinum)
3.2 ft/min (16.5ti, ti-S)2.5 ft/min (M15, 15-S)3.9 ft/min (M12, 12-S)

No Load Motor Current

65 amps (VR12, 12-S)66 amps (VR10, 10-S)69 amps (VR8, 8-S)
50 amps (ZEON 12, 12-S)62 amps (ZEON 10, 10-S)63 amps (ZEON 8, 8-S)
57 amps (12, 12-S Platinum)55 amps (10, 10-S Platinum)
68 amps (16.5ti-, ti-S)67 amps (M15, 15-S)67 amps (M12, 12-S)

Rated Load Motor Current

457 amps (VR12, 12-S)502 amps (VR8, 10-S)457 amps (VR8, 8-S)
438 amps (ZEON 12, 12-S)409 amps (ZEON 10, 10-S)413 amps (ZEON 8, 8-S)
446 amps (12, 12-S Platinum)465 amps (10, 10-S Platinum)
460 amps (M15, 15-S)440 amps (M12, 12-S)

Corrosion Resistance

204 hr salt spray test
408 hr salt spray test
408 hr salt spray test
408 hr salt spray test

Ingress Protection

Winch is dust tight,weather-resistant,with IP68 waterproofelectrical contactor
Entire winch unit israted IP68 waterproof, forsubmersible operation,including remote
Entire winch unit is ratedIP68 waterproof, for submersibleoperation, includingremote
Winch is dust tight,weather-resistant, withIP68 waterproof electricalcontactor

Motor

Standard-dutyWARN-engineered motor
High-performance, high effiencymotor, exclusiveto ZEON
Highest-performance motor exclusive to the Platinum
High-performance motor exclusive to the Heavyweights

Geartrain Durability

★★★
★★★★
★★★★★
★★★★★

Warranty

Mechanical

Limited Lifetime
Limited Lifetime
Limited Lifetime
Limited Lifetime

Electrical

7 Years
7 Years
7 Years
7 Years
